Deep Trench MOS Capacitor 1000pF 50V High Density Single Layer Chip For Stable DC Bias Operation

Name: Deep Trench MOS Capacitor 1000pF 50V High Density Single Layer Chip For Stable DC Bias Operation
Brand: Hoan
Price: 1 USD

Best Deep Trench MOS Capacitor 1000pF 50V High Density Single Layer Chip For Stable DC Bias Operation wholesale

Chip Dimensions : 0.50 × 0.50 × 0.18 mm (±25 µm); custom geometry up to 4:1 aspect ratio

MOQ : 10 Pieces

Insulation Resistance : ≥10⁴ MΩ @ rated voltage, 25°C

ESD Tolerance : >2 kV HBM, Class 2 (JESD22-A114)

Leakage Current : <10 nA @ 25°C; <500 nA @ 200°C (at rated voltage)

Brand Name : Hoan

Place of Origin : Shaanxi, China

Operating / Storage Temperature : -55°C to +200°C / -65°C to +150°C

Delivery Time : 5-7 working days for stock, 3-4 weeks for production

DC Bias Stability : Stable C-V under sustained rated DC bias; lot-level bias-temperature stress (BTS) screening

Payment Terms : L/C,D/A,D/P,T/T

Certification : ISO 9001:2015, RoHS

Hot Carrier Resistance : Low-defect thermal SiO2 limits hot-carrier-induced drift under DC bias

Model Number : HACC102T50V601

Contact Now

HACC102T50V601 Deep-Trench MOS Capacitor — 1000 pF 50 V High-Density Single Layer Chip with Bias-Stable Dielectric

The HACC102T50V601 is a 1000 pF ±10% single-layer MOS capacitor rated at 50 V DC, built on a 3D deep-trench silicon architecture in which deep trenches etched into the silicon substrate multiply the effective electrode area within the same die footprint. The capacitor delivers 1000 pF in a 0.50 mm × 0.50 mm die; for reference, planar 1000 pF MOS capacitors in this series use 0.75 mm-class die, so the trench design provides roughly twice the capacitance per unit area for space-constrained hybrid modules. A MOS capacitor is a single-layer capacitor formed by a metal-oxide-semiconductor structure (thermal silicon dioxide on a conductive silicon substrate), valued for low ESL, stable capacitance and high insulation resistance.

3D Deep-Trench Architecture for Ultra-High Volumetric Efficiency

Etched trench electrodes increase effective plate area per unit footprint, achieving 1000 pF at 50 V in a 0.50 × 0.50 mm outline with a 0.18 mm profile;
Roughly 2× area efficiency versus planar 1000 pF MOS capacitors of this series, freeing carrier area for additional die in hybrid microcircuits;
Full bottom-side metallization preserves maximum thermal contact and low-inductance current path despite the 3D structure;
Custom trench layouts, die sizes and aspect ratios (up to 4:1) are available for customer-specific footprints.

Electrical Characteristics (typical, 25°C unless noted)

Nominal Capacitance	1000 pF ±10% (1 kHz, 1.0 Vrms); ±5% available
Rated Voltage	50 V DC
Dielectric Withstanding Voltage	125 V DC (250% rated, 5 s, 100% tested)
Temperature Coefficient (TCC)	+35 ppm/°C over -55°C to +200°C
Dissipation Factor	≤0.15% at 1 kHz, 1.0 Vrms
Q Factor	>2000 at 1 MHz
ESR	<0.1 Ω @ 1 GHz
Intrinsic Chip ESL	<0.05 nH (de-embedded)
Leakage Current	<10 nA at 25°C; <500 nA at 200°C (at rated voltage)
Insulation Resistance	≥10⁴ MΩ at rated voltage, 25°C
ESD Tolerance	>2 kV HBM, Class 2 per JESD22-A114
Operating / Storage Temperature	-55°C to +200°C / -65°C to +150°C
Standard Die Size	0.50 × 0.50 × 0.18 mm (±25 µm); custom geometry, aspect ratio up to 4:1
Metallization	TiW-Au top (≥2.5 µm Au, wire bondable); TiW-Pt-Au backside for AuSn / conductive epoxy

Typical Applications

Compact DC bias decoupling and bypass in hybrid microcircuits and multi-chip modules; RF power amplifier bias networks; space-constrained microwave assemblies; filter and timing networks requiring bias-stable capacitance; high-density energy storage in pulsed circuits.
